Appareil d’anesthésie médicale avec moniteur patient YSAV850
| Product parameters | |
| Brand: | YSENMED |
| MOQ: | 1 |
| Package: | Wooden Package |
| Ship From: | Guangzhou |
| Lead Time: | 7 days |
| Customization: | Customized packaging |
Description
Medical Anesthesia Machine With Patient Monitor
YSAV850 Medical Anesthesia Machine is equipped with an accurate dedicated anesthetic vaporizer and a safety device for preventing cyanosis and necessary alarm system. During the anesthesia, the patient’s respiratory functions can be managed by using a microcomputer controlled pneumatic electrically controlled synchronizing anesthesia respirator. Each connection part of the whole machine is a standard interface. A highly efficient and large volume soda lime absorber can minimize the re-inhalation of carbon dioxide by the patient.
Specifications:
| Two vaporizers | Choose from Enflurane/Isoflurane/Sevoflurane; (Option: Halothane) |
| Oxygen Flush | 25~75 L/Min; |
| Respiration Mode | IPPV, SIPPV(VCV), IMV, SIMV, PEEP, Manu, Sigh |
| Tidal Volume | 0~1500 mL; |
| I:E | 8:1~1:10; |
| Respiration Frequency | 1~100bpm; |
| PEEP | 1~10 hPa; |
| Ptr | -10~10 hPa; |
| CO2 absorber capacity | 1 kg |
| Lung compliance | ≤ 30 mL/kPa; |
| IMV frequency | 1~12bpm |
| Inspiratory Plateau | 0~1S; |
| O2 Concentration | 21%~100% |
| Alarm parameter | upper /lower limit of airway pressure, tidal volume exceed limitation, no tidal volume output, apnea, AC power malfunction, battery low power |
Pneumatically driven electronically controlled system
Built-in ventilator, 10.4” LCD screen
With 1 patient circuit for adult (Option: patient circuit for children).
5-tube flowmeters, O2 & N2O & Air;0.1 L/Min ~ 10 L/Min;
